Product Design

Product design is about the creation of attractive and functional products through a series of practical development stages. It can start with an idea, a problem to be solved, a market opportunity, or an existing product in need of improvement, and may require a combination of ergonomics, aesthetics, and design for manufacture for small or large volume.

The project generally starts with concept sketches, developing through computer modelling, rapid prototyping, 3D printing or other types of model (great tools for market testing and sourcing funding), to detail design and specifications for the finished product. We can also work with you on just a key section of the development process, such as visualisation of an idea to explore market reaction and help raise funding. We can also help you explore more sustainable materials with a view to reducing environmental impact whilst maintaining profitability. KDC can provide critical input as part of a client team, or provide a wider skill set often needed for the individual client.

Below is a retrospective gallery of some of the product design work undertaken over the last four decades, including some technical illustrations.

1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

17 18 19 20

21 22 23 24

25 26 27 28

29 30 31 32

33 34 35 36

37 38 39 40

Gallery: 1 Electronically controllable central heating system. 2 Anti-viral air sterilisation units. 3 Robust modular seating for transport hubs. 4 Wrist tag element of asset tracking system. 5 Generator for innovative cancer treatment. 6 Low energy electronically controlled Solo heater. 7 Solo heater corner detail. 8 Low energy ducted air heating and cooling system. 9 Patent protected key operated street socket. 10 Cast ductile iron bins. 11 Cast ductile iron framed seating. 12 Curved modular seating using composite recycled timber. 13 Hanging basket poles. 14 Modular ductile iron planter. 15 Modular robust seating. 16 Cast ductile iron and timber bench. 17 Remote camera receiver. 18 Remote camera transmitter. 19 Screen cleaner low cost housing with integral spray. 20 Multi-battery charger with interchangeable adaptors. 21 Coffee machine - one of a range. 22 Coffee machine exploded view. 23 Coffee machine bulk brewer. 24 Range cooker for leading Irish brand. 25 Cast iron gas-fired stove. 26 Stretcher for leading emergency equipment manufacturer. 27 Modular system for handling medical waste receptacles. 28 Flow controller for intravenous drip. 29 Multi-purpose stepladder concept for entrepreneur. 30 Patented outdoor quartz electric heater. 31 Tamper-evident mini container for product sample. 32 One-piece injection-moulded lid for baby milk powder. 33 Robust backpack with detachable daybed. 34 Backpack support system illustration. 35 Illustration of milk collection system. 36 Section view of air purification system. 37 Illustration of low energy heating system. 38 Technical illustration for cooling system. 39 Technical illustration of electrical cabinet. 40 Concept sketches before 3D CAD.
